Water carbonator made of AISI 316 stainless steel, designed for water treatment and cooling applications where strength, reliability and compact size are essential. The 76 mm outer body diameter and Ø 8 mm (5/16") connections make it suitable for integration into chilled and sparkling water dispensing systems. The unit is equipped with a safety valve and can be installed in vertical or horizontal position, offering greater flexibility during assembly. Technical features: AISI 316 stainless steel body

This product is planned for the production of sparkling water using exclusively carbon dioxide up to the maximum pressure of 7 bar with potable water. Technical features: - Level control with one probe - Ground Faston - Two single check valves on inlet water - Two single check valves on inlet co2 Gas - Water inlet thread 1/4” gas - Gas inlet thread 1/4” gas - Output probe fitting connection 8mm(5/16”) - Bottom drain with cap - Max. operating pressure = 7bar(101psi) - Bursting pressure = 80bar(1

- Level control with one probe; - Made of stainless steel AISI 316; - Antibacterial silver welds; - Horizontal or vertical functioning; - Both internal and external pickling (metal)*. Technical features: - Water inlet stem OD8mm. - Water outlet stem OD8mm. - Co2 inlet stem OD8mm. - Max. operating pressure= 7bar. (102 psi). - Safety valve breather start= 8bar. (116psi). - Bursting pressure = > 20 bar. (290 psi). - Carbonator max. capacity = 2lt./min. 12bar.(732psi) h2o, pump 300lt./h.

Technical features: - Made of stainless steel AISI 304, - Probe for level control, - Probe for temperature control, - Overall capacity: 2ltr., - Capacity per partition: 1ltr. lower partition H2O still - 1 ltr. upper partition SODA, - Cast TIG welding, - Vertical functioning, - Both internal and external pickling and passitivation (metal) - Water inlet thread: OD 8mm., - Water outlet thread: OD 8mm., - Gas inlet thread: OD 8mm., - Max. operating pressure: 7bar (101 psi), - Bursting pre

Replacement safety valve for water carbonator 060116, 060119

Technical features: - Level control with double probe - Made of stainless steel AISI 316 - Antibacterial silver welds - Horizontal or vertical functioning - Both internal and external pickling (metal) - Water inlet thread 1/8” gas - Water outlet thread 1/8” gas - Gas inlet thread 1/8” gas - Max. operating pressure = 8,5 bar (123 psi) - Bursting pressure = > 20 bar (290 psi) - Carbonator max. capacity = 2lt./min 12bar(732psi) h2o, pump 300lt./h., 4bar(58psi) Co2. Pickling is a metal surface tr

Features: Material: tinned brass Color: red Max. rating: 10A

Features: Material: tinned brass Color: yellow Max. rating: 24A

Features: Material: tinned brass Max. working temperature: 110°C Cable diameter: 0,30-0,80 mm.

Insertion from behind. Features: Material: natural polyethylene Insulator diameter: 2,5mm.

Features: Material: tinned brass Color: red Max. rating: 19A

Flame retardant and resistant to solvents and chemical agents. Flexible and highly insulated. Many useful applications including terminal connections, electrical insulation, mechanical protection, wire identification and color coding. Features: Shrink fact: 2:1 Material: polyolefin Shrink temperature: 120°C Work temperature: -40° - 135°C Restrict diameter: 1,6mm. Normal diameter: 3,2mm.

Features: Material: natural brass

Features: Material: pvc Color: natural

1-way solenoide valve with body in food grade resin membrane in platinic silicone 3/4"x1/4" Flow rate: 2,5 Lt./Min. - 2,5bar Nominal pressure: 10bar

Solenoid valve R series - 230V. AC thread 3/4" M. - quick fit JG 8mm. with plastic bracket

Servo-assisted solenoid valve for water with integrated flow sensor. This valve is typically used on household appliances connected to the hydraulic network. A flow sensor, capable of measuring the volume of delivered water, and a flow limiter, capable of

Normally closed.

3-ways solenoide valve, with body in food grade resin and membrane in platinic silicone 3/4" x 1/4". Flow rate: 6,7 Lt./Min. - 3,5bar. Nominal pressure: 10bar. Voltage: 220V. - AC Voltage: 24V. - DC

Solenoid valve connection faston for cod. 20030023 Normally Closed (NC).

Solenoid valve new version with JG 6mm. quick fit for cod. 20030023

Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket

Features: Structure: POM Compensator: NBR / LSR Work features Fluid direction: Unidirectional Working pressure: 0-10bar. (0-1Mpa)

MAX RAT.:100 mW WORK. TEMP.:-40°C - +80°C
