WHAT ARE UV RAYS
The small part of electro-magnetic spectrum having wave lengths included between 100 and 400 nm (thousandths of micron) is defined as space of the ultra-violet irradiation. The UV-C are part of the subspace characterized by the wave lengths included between 100 and 280 nm. Electro-magnetic waves with different wave length and width induce interactions with the matter of different nature, the UV-C irradiation with l= 254nm is particularly interesting thanks to its marked germicidal power.

System Ultrarays UV Water Sterilizers Reverse Osmosis Prefiltration Germicidial Action 4W 6W 11W 16W 25W 30W 55W

WHY DO THEY WORKS
The high germicidal power of this wave length must be sought in DNA and in the link of its fundamental components (nucleotids). DNA is a macromolecule present in all living organisms in which all information necessary for life and reproduction reside. The alteration, induced by the UV-C irradiation, of some chemical links present among nucleotids is able to change the information contained and conveyed by DNA, these alterations prevent its normal activity and this irreversibly leads to the cellular death.

HOW MUCH DO THEY WORK
For being effective in the disinfection, an electro-magnetic wave, besides being of a certain kind (L = 254nm) it must possess also a minimum value of intensity to be able to ensure a minimum dose to water. A UV sterilizer, if correctly sized, is able to give water a dose sufficient for reducing almost all the commonest micro-organisms present in water. Normally a UV disinfection system must have a UV dose higher than 300 J/m2.

HOW THEY ARE PRODUCED
In nature the UV-C rays are part of the secondary cosmic irradiation which, interacting with the high strata of the terrestrial atmosphere, generates ozone and with a lower energy, it reaches ground as tanning UV(A+B) irradiation. Artificially UV-C rays are produced with the help of special fluorescent lamps containing mercury fumes, these lamps are made of a very pure quartz (>99.99% SiO2) transparent to the UV-C light which they emit in an almost monochromatic form (>95% of Ć = 254nm).

WHY THEY ARE CONVENIENT
Among the several advantages offered by this kind of technology we mention:
- environmental treatment (without addition of chemicals, without alteration of taste)
- no danger of over-dosing and no alteration of the characteristic of water
- quick action (without any stocking tank) the time is the one of passing through the sterilizer
- compatibility with the other technologies (filtration, softening, etc) for a complete treatment of water
- cheapness and practicalness thanks to the low consumption of electrical energy and to the little required servicing.

APPLICATIONS
Point of entry(POE) in the home or industry, point of use(POU) for water purifiers such as reverse osmosis, microfiltration, drinking water, food processing such as dairy companies, restaurants, beer factories and bakeries, medical, industrial processing, aquarium, swimming pool units, aquaculture, laboratories.


Reverse Osmosis Installation
System Ultrarays UV Water Sterilizers Reverse Osmosis Prefiltration Germicidial Action 4W 6W 11W 16W 25W 30W 55W
Industrial and Residential Use
System Ultrarays UV Water Sterilizers Reverse Osmosis Prefiltration Germicidial Action 4W 6W 11W 16W 25W 30W 55W

BENEFITS
Philips Germicidal Sterilamp uses UV-C technology, which allows for the emission of UV-C energy to disinfect water. The Philips Germicidal Sterilamp is then a cost effective and environmentally responsible disinfection alternative to chemical for water treatment.
- Effective for all types of microorganisms, including bacteria, viruses, fungus, and protozoa such as Cryptosporidium and Giardia.
- No disinfection by-products (DBPs) of health concern formed.
- UVC acts instantly.
- Low capital and operating cost.
- Easy to operate and maintain.
- Does not change the water taste.
- Safe and environmentally-friendly.
- No overdose issues and dose can be easily adapted to specific needs.

order
other filters

UV Lamp Complete Set, 2lt./min. (0,5 GPM) filtered water - 4lt./min. (1 GPM) osmotized water 6W - 1/4"
UV Lamp Complete Set, 2lt./min. (0,5 GPM) filtered water - 4lt./min. (1 GPM) osmotized water 6W - 1/4"
12000001
Size: [Cod.: 12000001-01] Ø64 x L300 (mm) [Cod.: 12000001-02] Ø15,5 x L212 (mm) [Cod.: 12000001-03] Ø23 x L240 (mm)
details
Flow rate filtered water:
2LT/MIN. (0,5 GPM)
Flow rate osmotized water:
4LT/MIN. (1 GPM)

UV Lamp Complete Set, 6lt./min. (1,58 GPM) filtered water - 8lt./min. (2,11 GPM) osmotized water 14W - 1/4"
UV Lamp Complete Set, 6lt./min. (1,58 GPM) filtered water - 8lt./min. (2,11 GPM) osmotized water 14W - 1/4"
12000002
Size: [Cod.: 12000002-01] Ø64 x L340 (mm) [Cod.: 12000002-02] Ø15 x L287 (mm) [Cod.: 12000002-03] Ø23 x L330 (mm)
details
Flow rate filtered water:
6LT/MIN. (1,58 GPM)
Flow rate osmotized water:
8LT/MIN. (2,11 GPM)

UV Lamp Complete Set, 14,4lt./min. (3,8 GPM) filtered water - 20lt./min. (5,28 GPM) osmotized water 24W - 1/2"
UV Lamp Complete Set, 14,4lt./min. (3,8 GPM) filtered water - 20lt./min. (5,28 GPM) osmotized water 24W - 1/2"
12000003
Size: [Cod.: 12000003-01] Ø64 x L512 (mm) [Cod.: 12000003-02] Ø15,5 x L450 (mm) [Cod.: 12000003-03] Ø23 x L500 (mm)
details
Flow rate filtered water:
14,4LT/MIN. (3,8 GPM)
Flow rate osmotized water:
20LT/MIN. (5,28 GPM)

UV Lamp Complete Set, 23,33lt./min. (6,16 GPM) filtered water - 28,33lt./min. (7,48 GPM) osmotized water 32W - 1/2"
UV Lamp Complete Set, 23,33lt./min. (6,16 GPM) filtered water - 28,33lt./min. (7,48 GPM) osmotized water 32W - 1/2"
12000004
Size: [Cod.: 12000004-01] Ø64 x L680 (mm) [Cod.: 12000004-02] Ø15 x L650 (mm) [Cod.: 12000004-03] Ø23 x L670 (mm)
details
Flow rate filtered water:
23,33LT/MIN. (6,16 GPM)
Flow rate osmotized water:
28,33LT/MIN. (7,48 GPM)

UV Lamp Complete Set, 46,66lt./min. (12,32 GPM) filtered water - 55lt./min. (14,52 GPM) osmotized water 39W - 3/4"
UV Lamp Complete Set, 46,66lt./min. (12,32 GPM) filtered water - 55lt./min. (14,52 GPM) osmotized water 39W - 3/4"
12000005
Size: [Cod.: 12000005-01] Ø83 x L900 (mm) [Cod.: 12000005-02] Ø15,5 x L842 (mm) [Cod.: 12000005-03] Ø23 x L895 (mm)
details
Flow rate filtered water:
46,66LT/MIN. (12,32 GPM)
Flow rate osmotized water:
55LT/MIN. (14,52 GPM)

Replacement quartz Oring for UV systems 14, 24, 32, 39 Watt
Replacement quartz Oring for UV systems 14, 24, 32, 39 Watt
12000011
For UV systems code: 12000002, 12000003, 12000004, 12000005
Replacement UV ballast 220V./50Hz 24~39W. with alarm
Replacement UV ballast 220V./50Hz 24~39W. with alarm
12000010
Replacement ballast for UV systems. Suited for items: 12000003, 12000004, 12000005, 12000008.
UV Lamp Complete Set, from 5lt./min. (1,32 GPM) to 10lt./min. (2,5 GPM) 12W, 16W - 1/8", 3/8", 1/2"
UV Lamp Complete Set, from 5lt./min. (1,32 GPM) to 10lt./min. (2,5 GPM) 12W, 16W - 1/8", 3/8", 1/2"
12000006
Designed to destroy any bacteria in the water. The deep biostrutturale disorder that causes the beam on the bacteria, interferes with the ability to reproduce every type of microorganism, making it harmless. Is advised to install a filter upstream of the UV sterilizer, and in this way impurities of every kind and texture are retained. This device is essential if you want to achieve a high level of disinfection in fact, the lack of filtration and removal of particles suspended in water, results in decreased
UltrARays LCD UV Systems Complete Set, from 20lt/min.(5,28 GPM) to 200lt/min.(52,83 GPM) 30W., 40W., 80W., 160W. - 3/4", 1", 1-1
UltrARays LCD UV Systems Complete Set, from 20lt/min.(5,28 GPM) to 200lt/min.(52,83 GPM) 30W., 40W., 80W., 160W. - 3/4", 1", 1-1
12000009
The UV sterilizers of UltrARays series have been planned specially for destroying harmful bacteria and viruses present in water. Their working is based on a physical principle which is a warrant of security: the output of ultra-violet irradiation. The UV light given out by special mercury fumes lamps (UV-C rays Wavelength=254nm) is highly germicidal because it interacts with DNA and RNA, at a molecular level. The deep bio-structural disorder caused by such irradiation interferes with the development and th
details
Flow rate filtered water(UV20):
20LT/MIN. (5,28 GPM)
Flow rate filtered water(UV45):
45LT/MIN. (11,88 GPM)
Flow rate filtered water(UV60):
60LT/MIN (15,85GPM)
Flow rate filtered water(UV75):
75LT/MIN (19,81 GPM)
Flow rate filtered water(UV85):
85LT/MIN (22,45 GPM)
Flow rate filtered water(UV100):
100LT/MIN (26,41 GPM)
Number Lamps (UV20):
1
Number Lamps (UV45):
1
Number Lamps (UV60):
1
Number Lamps (UV75):
2
Number Lamps (UV85):
1
Number Lamps (UV100)
2
Number Lamps (UV200):
2
Power consumption (UV20):
30W
Power consumption (UV45,UV60):
40W
Power consumption (UV75):
80W
Power consumption (UV85):
80W
Power consumption (UV100):
80W
Power consumption (UV200):
160W
Transmittance UVC:
99% - 1cm.
UV-C Dose(J/m2)(UV20):
300
UV-C Dose(J/m2)(UV45):
300
UV-C Dose(J/m2)(UV60):
300
UV-C Dose(J/m2)(UV75):
300
UV-C Dose(J/m2)(UV85):
300
UV-C Dose(J/m2)(UV100,UV200):
400
Lamp Lifespan:
9.000 h.
Manifold material:
Stainless Steel AISI 304 (AISI 316 on request)
Pressure:
10bar (145psi)
Power supply:
220/230V - 50/60Hz - Spina Europea tipo schuko
LCD elettrical panel:
LCD, LCD PRO versions
Panel protection degree:
IP55 (LCD, LCDPRO versions)
LCD Display:
Microprocessor Control (LCD, LCDPRO versions)
Hour-meter:
LCD, LCD PRO versions
Red led of anomaly:
LCD, LCD PRO versions
Alarm relay contact:
Free NO/NC (LCD, LCD PRO versions)
Alarm relay outlet:
230V NA/NC 2a Max (LCD, LCD PRO versions)
Resettable countdown hour-meter:
with alarm for end lamp life (only LCD PRO)
Display of control:
Irradiation/temperature (only LCD PRO)
Automatic shutdown:
For high temperature UV chamber (only LCD PRO)
Contact option:
On request - 4/20 mA + remote on/off (only LCD PRO)

UltraRays UV Lamp Complete Set, 0,8lt./min. (0,21 GPM) filtered water - 0,95lt./min. (0,25 GPM) osmotized water 4W - 1/4"
UltraRays UV Lamp Complete Set, 0,8lt./min. (0,21 GPM) filtered water - 0,95lt./min. (0,25 GPM) osmotized water 4W - 1/4"
12012006
AISI 304 stainless steel body, the system is inclusive of clips for the fixing. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 0,8LT/MIN. (0,21 GPM) * Flow rate osmotized water: 0,9lt/min. (0,23 GPM) * Power supply: 220-240V 50/60Hz 0,03A * Rating power: 5,5W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 187 x Ø 51
details
Flow rate filtered water:
0,8LT/MIN. (0,21 GPM)
Flow rate osmotized water:
0,9lt/min. (0,23 GPM)

UltraRays UV Lamp Complete Set, 1,3lt./min. (0,35 GPM) filtered water - 1,8lt./min. (0,48 GPM) osmotized water 6W - 1/4"
UltraRays UV Lamp Complete Set, 1,3lt./min. (0,35 GPM) filtered water - 1,8lt./min. (0,48 GPM) osmotized water 6W - 1/4"
12012007
AISI 304 stainless steel body, the system is inclusive of clips for the fixing. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 1,3LT/MIN. (0,35 GPM) * Flow rate osmotized water: 1,8LT/MIN. (0,48 GPM) * Power supply: 220-240V 50/60Hz 0,03A * Rating power: 8W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 251 x Ø 51
details
Flow rate filtered water:
1,3LT/MIN. (0,35 GPM)
Flow rate osmotized water:
1,8LT/MIN. (0,48 GPM)

UltraRays UV Lamp Complete Set, 1,3lt./min. (0,35 GPM) filtered water - 1,8lt./min. (0,48 GPM) osmotized water 6W - 1/4"
UltraRays UV Lamp Complete Set, 1,3lt./min. (0,35 GPM) filtered water - 1,8lt./min. (0,48 GPM) osmotized water 6W - 1/4"
12012019
AISI 304 stainless steel body, the system is inclusive of clips for the fixing. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 1,3LT/MIN. (0,35 GPM) * Flow rate osmotized water: 1,8LT/MIN. (0,48 GPM) * Power supply: 220-240V 50/60Hz 0,03A * Rating power: 8W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 257 x Ø 51
details
Flow rate filtered water:
1,3LT/MIN. (0,35 GPM)
Flow rate osmotized water:
1,8LT/MIN. (0,48 GPM)

UltraRays Lamp Complete Set, 3lt./min. (0,8 GPM) filtered water - 3,8lt./min. (1 GPM) osmotized water 11W - 1/4"
UltraRays Lamp Complete Set, 3lt./min. (0,8 GPM) filtered water - 3,8lt./min. (1 GPM) osmotized water 11W - 1/4"
12012008
AISI 304 stainless steel body, the system is inclusive of clips for the fixing. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 3LT/MIN. (0,8 GPM) * Flow rate osmotized water: 3,8LT/MIN. (1 GPM) * Power supply: 220-240V 50/60Hz 0,07A * Rating power: 14W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 251 x Ø 51
details
Flow rate filtered water:
3LT/MIN. (0,8 GPM)
Flow rate osmotized water:
3,8LT/MIN. (1 GPM)

UltraRays UV Lamp Complete Set, 6,05lt./min. (1,6 GPM) filtered water - 7,57lt./min. (2 GPM) osmotized water 16W - 1/2"
UltraRays UV Lamp Complete Set, 6,05lt./min. (1,6 GPM) filtered water - 7,57lt./min. (2 GPM) osmotized water 16W - 1/2"
12012009
AISI 304 stainless steel body, the system is inclusive of clips for the fixing. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 6,05 LT/MIN. (1,6 GPM) * Flow rate osmotized water: 7,57 LT/MIN. (2 GPM) * Power supply: 220-240V 50/60Hz 0,07A * Rating power: 21W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 365 x Ø 64
details
Flow rate filtered water:
6,05LT/MIN. (1,6 GPM)
Flow rate osmotized water:
7,57LT/MIN. (2 GPM)

UltraRays UV Lamp Complete Set, 19lt./min. (5 GPM) filtered water - 22,66lt./min. (5,98 GPM) osmotized water 25W - 1/2"
UltraRays UV Lamp Complete Set, 19lt./min. (5 GPM) filtered water - 22,66lt./min. (5,98 GPM) osmotized water 25W - 1/2"
12012010
AISI 304 stainless steel body, the system is inclusive of clips for the fixing. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 19 LT/MIN. (5 GPM) * Flow rate osmotized water: 22,66 LT/MIN. (5,98 GPM) * Power supply: 220-240V 50/60Hz 0,11A * Rating power: 32W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 507 x Ø 64
details
Flow rate filtered water:
19LT/MIN. (5 GPM)
Flow rate osmotized water:
22,66LT/MIN. (5,98 GPM)

UltraRays UV Lamp Complete Set, 25lt./min. (6,6 GPM) filtered water - 30,33lt./min. (8 GPM) osmotized water 30W - 3/4"
UltraRays UV Lamp Complete Set, 25lt./min. (6,6 GPM) filtered water - 30,33lt./min. (8 GPM) osmotized water 30W - 3/4"
12012011
AISI 304 stainless steel body, the system is inclusive of clips for the fixing. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 25 LT/MIN. (6,6 GPM) * Flow rate osmotized water: 30,33 LT/MIN. (8 GPM) * Power supply: 220-240V 50/60Hz 0,14A * Rating power: 40W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 962 x Ø 64
details
Flow rate filtered water:
25LT/MIN. (6,6 GPM)
Flow rate osmotized water:
30,33LT/MIN. (8 GPM)

UltraRays UV Lamp Complete Set, 38lt./min. (10 GPM) filtered water - 45,5lt./min. (12 GPM) osmotized water 55W - 3/4"
UltraRays UV Lamp Complete Set, 38lt./min. (10 GPM) filtered water - 45,5lt./min. (12 GPM) osmotized water 55W - 3/4"
12012012
AISI 304 stainless steel body, the system is inclusive of clips for the fixing. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 38 LT/MIN. (10 GPM) * Flow rate osmotized water: 45,5 LT/MIN. (12 GPM) * Power supply: 220-240V 50/60Hz 0,25A * Rating power: 72W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 968 x Ø 64
details
Flow rate filtered water:
38LT/MIN. (10 GPM)
Flow rate osmotized water:
45,5LT/MIN. (12 GPM)

UltraRays UV Lamp Complete Set, 60lt./min. (15,85 GPM) filtered water - 75lt./min. (19,81 GPM) osmotized water 75W - 1"
UltraRays UV Lamp Complete Set, 60lt./min. (15,85 GPM) filtered water - 75lt./min. (19,81 GPM) osmotized water 75W - 1"
12012013
AISI 304 stainless steel body, the system is inclusive of S.S. clips for the fixing. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 60 LT/MIN. (15,87 GPM) * Flow rate osmotized water: 75 LT/MIN. (20 GPM) * Power supply: 110-240V 50/60Hz 1.03A - 0,47A * Rating power: 98W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 968 x Ø 64 Ballast with timer and control panel. - Press "S" switch to switch display screen between l
details
Flow rate filtered water:
60LT/MIN (15,85 GPM)
Flow rate osmotized water:
75LT/MIN (19,81 GPM)

UltraRays UV Lamp Complete Set, 76lt./min. (20 GPM) filtered water - 90,72lt./min. (24 GPM) osmotized water 110W - 1"
UltraRays UV Lamp Complete Set, 76lt./min. (20 GPM) filtered water - 90,72lt./min. (24 GPM) osmotized water 110W - 1"
12012014
AISI 304 stainless steel body, the system is inclusive of the pedestal. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 76 LT/MIN. (20 GPM) * Flow rate osmotized water: 90,72 LT/MIN. (24 GPM) * Power supply: 2x 200-240V 50/60Hz 0,25A * Rating power: 143W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 965 x Ø 108
details
Flow rate filtered water:
76LT/MIN (20 GPM)
Flow rate osmotized water:
90,72LT/MIN (24 GPM)

UltraRays UV Lamp Complete Set, 114lt./min. (30 GPM) filtered water - 136lt./min. (36 GPM) osmotized water 165W - 1-1/2"
UltraRays UV Lamp Complete Set, 114lt./min. (30 GPM) filtered water - 136lt./min. (36 GPM) osmotized water 165W - 1-1/2"
12012015
AISI 304 stainless steel body, the system is inclusive of the pedestal. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 114 LT/MIN. (30 GPM) * Flow rate osmotized water: 136 LT/MIN. (36 GPM) * Power supply: 3x 200-240V 50/60Hz 0,25A * Rating power: 216W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 969 x Ø 133
details
Flow rate filtered water:
114 LT/MIN (30 GPM)
Flow rate osmotized water:
136 LT/MIN (36 GPM)

UltraRays UV Lamp Complete Set, 151lt./min. (40 GPM) filtered water - 181lt./min. (48 GPM) osmotized water 220W - 1-1/2"
UltraRays UV Lamp Complete Set, 151lt./min. (40 GPM) filtered water - 181lt./min. (48 GPM) osmotized water 220W - 1-1/2"
12012016
AISI 304 stainless steel body, the system is inclusive of the pedestal. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 151 LT/MIN. (40 GPM) * Flow rate osmotized water: 181 LT/MIN. (48 GPM) * Power supply: 4x 200-240V 50/60Hz 0,25A * Rating power: 286W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 969 x Ø 133
details
Flow rate filtered water:
151LT/MIN (40 GPM)
Flow rate osmotized water:
181LT/MIN (48 GPM)

UltraRays UV Lamp Complete Set, 227lt./min. (60 GPM) filtered water - 272lt./min. (72 GPM) osmotized water 330W - 2"
UltraRays UV Lamp Complete Set, 227lt./min. (60 GPM) filtered water - 272lt./min. (72 GPM) osmotized water 330W - 2"
12012017
AISI 304 stainless steel body, the system is inclusive of the pedestal. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 227 LT/MIN. (60 GPM) * Flow rate osmotized water: 272 LT/MIN. (72 GPM) * Power supply: 6x 200-240V 50/60Hz 0,25A * Rating power: 432W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 969 x Ø 168
details
Flow rate filtered water:
227LT/MIN (60 GPM)
Flow rate osmotized water:
272LT/MIN (72 GPM)

UltraRays UV Lamp Complete Set, 303lt./min. (80 GPM) filtered water - 363lt./min. (96 GPM) osmotized water 440W - 3"
UltraRays UV Lamp Complete Set, 303lt./min. (80 GPM) filtered water - 363lt./min. (96 GPM) osmotized water 440W - 3"
12012018
AISI 304 stainless steel body, the system is inclusive of the pedestal. * Max pressure: 10 bar (145 psi) * Ultraviolet radiation: 30.000 W/cm2 * Flow rate filtered water: 303 LT/MIN. (80 GPM) * Flow rate osmotized water: 363 LT/MIN. (96 GPM) * Power supply: 8x 200-240V 50/60Hz 0,25A * Rating power: 576W. * Philips average lamp life: 9.000h. - max. 1 year * Dimensions (mm.): L. 969 x Ø 219
details
Flow rate filtered water:
303LT/MIN (80 GPM)
Flow rate osmotized water:
363LT/MIN (96 GPM)

UltraRays replacement UV ballast 4W. - 6W.
UltraRays replacement UV ballast 4W. - 6W.
12012101
* Power supply: 220-240V 50/60Hz 0,03A * Rating power (12012006): 5,5W. * Rating power (12012007): 8W. For codes: 12012006 - 12012007
UltraRays replacement UV ballast 11W. - 16W.
UltraRays replacement UV ballast 11W. - 16W.
12012102
* Power supply: 220-240V 50/60Hz 0,07A * Rating power (12012008): 14W. * Rating power (12012009): 21W. For codes: 12012008 - 12012009
UltraRays replacement UV ballast 25W.
UltraRays replacement UV ballast 25W.
12012103
* Power supply: 220-240V 50/60Hz 0,11A * Rating power: 32W. For code: 12012010
UltraRays replacement UV ballast 30W.
UltraRays replacement UV ballast 30W.
12012104
* Power supply: 220-240V 50/60Hz 0,14A * Rating power: 40W. For code: 12012011
UltraRays replacement UV ballast 55W.
UltraRays replacement UV ballast 55W.
12012105
* Power supply: 220-240V 50/60Hz 0,25A * Rating power: 72W. For code: 12012012
UltraRays replacement UV ballast 75W.
UltraRays replacement UV ballast 75W.
12012118
* Power supply: 110-240V 50/60Hz 1.03A - 0,47A * Rating power: 98W. Ballast with timer and control panel. - Press "S" switch to switch display screen between lamp and ballast. - Press "S" switch to display total runnings days of ballast. - Press & hold on "S" switch to reset lamp life timer. - Press & hold on "S" switch to silent end of lamp life alarm for 7 days (4 time max.) For code: 12012013
UltraRays replacement UV quartz sleeve 4W.
UltraRays replacement UV quartz sleeve 4W.
12012106
For code: 12012006 Dimensions(mm.): Ø23 x L.180
45 products found - 2 pages
|< <<
1
2
>> >|
Customers Login
e-mail
password

CS series Water Softener Electronic Valve Regeneration Metered Time saving cleaning protection health pureness beauty  liters resin

Most viewed
 UV Systems
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

www.sinergroup.it Everpure Filters
