| DMfit LLDPE Tubing |
|
DMfit tubing is produced from an advanced grade of low density polyethylene. Its greatest advantage is superior environmental stress cracking resistance (ESCR), greatly exceeding that of ordinary polyethylene tubing as measured by ASTM D-1693 (IGEPAL) tests. Environmental stresses that can shorten the service life of tubing include chemical exposure, aging connections with barb-type fittings, or high vibration loads with connections to compression fittings. Our tubing is compliant to ANSI/NSF-51, 61, WRAS and FDA requirements for food contact applications. Our tubing is available in multiple coding colors, and offers the user : - Dimensional stability. - Uniformity and long-term strength. - Higher burst pressure. - Greater tensile strength. - Wide range of available colors. - Suitable for use with DMfit products and those of other manufacturers. |
| Working pressure and temperature | ||||||
 |
5/32" | 3/16" | 1/4" | 5/16" | 3/8" | 1/2" |
 |
4mm | 5mm | 6mm | 8mm | 10mm | 12mm |
| Pressure | 230psi | 170psi | ||||
| Tube tolerances | -0,1mm / +0,1mm | |||||
| Temperature | Air -20°C (-4°F) - 65°C (150°F) Liquid | |||||
|
* Pressure values are based on PE tube used at room temperature. |
||||||
| * Consult our representative when using at continuous elevated temperature and pressure. | ||||||
