12000001
Size:
[Cod.: 12000001-01] Ø64 x L300 (mm)
[Cod.: 12000001-02] Ø15,5 x L212 (mm)
[Cod.: 12000001-03] Ø23 x L240 (mm)
12000002
Size:
[Cod.: 12000002-01] Ø64 x L340 (mm)
[Cod.: 12000002-02] Ø15 x L287 (mm)
[Cod.: 12000002-03] Ø23 x L330 (mm)
12000003
Size:
[Cod.: 12000003-01] Ø64 x L512 (mm)
[Cod.: 12000003-02] Ø15,5 x L450 (mm)
[Cod.: 12000003-03] Ø23 x L500 (mm)
12000004
Size:
[Cod.: 12000004-01] Ø64 x L680 (mm)
[Cod.: 12000004-02] Ø15 x L650 (mm)
[Cod.: 12000004-03] Ø23 x L670 (mm)
details
Flow rate filtered water:
23,33LT/MIN. (6,16 GPM)
Flow rate osmotized water:
28,33LT/MIN. (7,48 GPM)
12000005
Size:
[Cod.: 12000005-01] Ø83 x L900 (mm)
[Cod.: 12000005-02] Ø15,5 x L842 (mm)
[Cod.: 12000005-03] Ø23 x L895 (mm)
details
Flow rate filtered water:
46,66LT/MIN. (12,32 GPM)
Flow rate osmotized water:
55LT/MIN. (14,52 GPM)
12000011
For UV systems code: 12000002, 12000003, 12000004, 12000005
12000010
Replacement ballast for UV systems.
Suited for items: 12000003, 12000004, 12000005, 12000008.
12000006
Designed to destroy any bacteria in the water. The deep biostrutturale disorder that causes the beam on the bacteria, interferes with the ability to reproduce every type of microorganism, making it harmless. Is advised to install a filter upstream of the UV sterilizer, and in this way impurities of every kind and texture are retained. This device is essential if you want to achieve a high level of disinfection in fact, the lack of filtration and removal of particles suspended in water, results in decreased
12000009
The UV sterilizers of UltrARays series have been planned specially for destroying harmful bacteria and viruses present in water. Their working is based on a physical principle which is a warrant of security: the output of ultra-violet irradiation.
The UV light given out by special mercury fumes lamps (UV-C rays Wavelength=254nm) is highly germicidal because it interacts with DNA and RNA, at a molecular level. The deep bio-structural disorder caused by such irradiation interferes with the development and th
details
Flow rate filtered water(UV20):
20LT/MIN. (5,28 GPM)
Flow rate filtered water(UV45):
45LT/MIN. (11,88 GPM)
Flow rate filtered water(UV60):
60LT/MIN (15,85GPM)
Flow rate filtered water(UV75):
75LT/MIN (19,81 GPM)
Flow rate filtered water(UV85):
85LT/MIN (22,45 GPM)
Flow rate filtered water(UV100):
100LT/MIN (26,41 GPM)
Number Lamps (UV20):
1
Number Lamps (UV45):
1
Number Lamps (UV60):
1
Number Lamps (UV75):
2
Number Lamps (UV85):
1
Number Lamps (UV100)
2
Number Lamps (UV200):
2
Power consumption (UV20):
30W
Power consumption (UV45,UV60):
40W
Power consumption (UV75):
80W
Power consumption (UV85):
80W
Power consumption (UV100):
80W
Power consumption (UV200):
160W
Transmittance UVC:
99% - 1cm.
UV-C Dose(J/m2)(UV20):
300
UV-C Dose(J/m2)(UV45):
300
UV-C Dose(J/m2)(UV60):
300
UV-C Dose(J/m2)(UV75):
300
UV-C Dose(J/m2)(UV85):
300
UV-C Dose(J/m2)(UV100,UV200):
400
Lamp Lifespan:
9.000 h.
Manifold material:
Stainless Steel AISI 304 (AISI 316 on request)
Pressure:
10bar (145psi)
Power supply:
220/230V - 50/60Hz - Spina Europea tipo schuko
LCD elettrical panel:
LCD, LCD PRO versions
Panel protection degree:
IP55 (LCD, LCDPRO versions)
LCD Display:
Microprocessor Control (LCD, LCDPRO versions)
Hour-meter:
LCD, LCD PRO versions
Red led of anomaly:
LCD, LCD PRO versions
Alarm relay contact:
Free NO/NC (LCD, LCD PRO versions)
Alarm relay outlet:
230V NA/NC 2a Max (LCD, LCD PRO versions)
Resettable countdown hour-meter:
with alarm for end lamp life (only LCD PRO)
Display of control:
Irradiation/temperature (only LCD PRO)
Automatic shutdown:
For high temperature UV chamber (only LCD PRO)
Contact option:
On request - 4/20 mA + remote on/off (only LCD PRO)
12012006
AISI 304 stainless steel body, the system is inclusive of clips for the fixing.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 0,8LT/MIN. (0,21 GPM)
* Flow rate osmotized water: 0,9lt/min. (0,23 GPM)
* Power supply: 220-240V 50/60Hz 0,03A
* Rating power: 5,5W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 187 x Ø 51
details
Flow rate filtered water:
0,8LT/MIN. (0,21 GPM)
Flow rate osmotized water:
0,9lt/min. (0,23 GPM)
12012007
AISI 304 stainless steel body, the system is inclusive of clips for the fixing.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 1,3LT/MIN. (0,35 GPM)
* Flow rate osmotized water: 1,8LT/MIN. (0,48 GPM)
* Power supply: 220-240V 50/60Hz 0,03A
* Rating power: 8W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 251 x Ø 51
details
Flow rate filtered water:
1,3LT/MIN. (0,35 GPM)
Flow rate osmotized water:
1,8LT/MIN. (0,48 GPM)
12012019
AISI 304 stainless steel body, the system is inclusive of clips for the fixing.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 1,3LT/MIN. (0,35 GPM)
* Flow rate osmotized water: 1,8LT/MIN. (0,48 GPM)
* Power supply: 220-240V 50/60Hz 0,03A
* Rating power: 8W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 257 x Ø 51
details
Flow rate filtered water:
1,3LT/MIN. (0,35 GPM)
Flow rate osmotized water:
1,8LT/MIN. (0,48 GPM)
12012008
AISI 304 stainless steel body, the system is inclusive of clips for the fixing.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 3LT/MIN. (0,8 GPM)
* Flow rate osmotized water: 3,8LT/MIN. (1 GPM)
* Power supply: 220-240V 50/60Hz 0,07A
* Rating power: 14W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 251 x Ø 51
12012009
AISI 304 stainless steel body, the system is inclusive of clips for the fixing.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 6,05 LT/MIN. (1,6 GPM)
* Flow rate osmotized water: 7,57 LT/MIN. (2 GPM)
* Power supply: 220-240V 50/60Hz 0,07A
* Rating power: 21W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 365 x Ø 64
12012010
AISI 304 stainless steel body, the system is inclusive of clips for the fixing.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 19 LT/MIN. (5 GPM)
* Flow rate osmotized water: 22,66 LT/MIN. (5,98 GPM)
* Power supply: 220-240V 50/60Hz 0,11A
* Rating power: 32W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 507 x Ø 64
12012011
AISI 304 stainless steel body, the system is inclusive of clips for the fixing.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 25 LT/MIN. (6,6 GPM)
* Flow rate osmotized water: 30,33 LT/MIN. (8 GPM)
* Power supply: 220-240V 50/60Hz 0,14A
* Rating power: 40W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 962 x Ø 64
12012012
AISI 304 stainless steel body, the system is inclusive of clips for the fixing.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 38 LT/MIN. (10 GPM)
* Flow rate osmotized water: 45,5 LT/MIN. (12 GPM)
* Power supply: 220-240V 50/60Hz 0,25A
* Rating power: 72W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 968 x Ø 64
12012013
AISI 304 stainless steel body, the system is inclusive of S.S. clips for the fixing.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 60 LT/MIN. (15,87 GPM)
* Flow rate osmotized water: 75 LT/MIN. (20 GPM)
* Power supply: 110-240V 50/60Hz 1.03A - 0,47A
* Rating power: 98W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 968 x Ø 64
Ballast with timer and control panel.
- Press "S" switch to switch display screen between l
12012014
AISI 304 stainless steel body, the system is inclusive of the pedestal.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 76 LT/MIN. (20 GPM)
* Flow rate osmotized water: 90,72 LT/MIN. (24 GPM)
* Power supply: 2x 200-240V 50/60Hz 0,25A
* Rating power: 143W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 965 x Ø 108
12012015
AISI 304 stainless steel body, the system is inclusive of the pedestal.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 114 LT/MIN. (30 GPM)
* Flow rate osmotized water: 136 LT/MIN. (36 GPM)
* Power supply: 3x 200-240V 50/60Hz 0,25A
* Rating power: 216W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 969 x Ø 133
12012016
AISI 304 stainless steel body, the system is inclusive of the pedestal.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 151 LT/MIN. (40 GPM)
* Flow rate osmotized water: 181 LT/MIN. (48 GPM)
* Power supply: 4x 200-240V 50/60Hz 0,25A
* Rating power: 286W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 969 x Ø 133
12012017
AISI 304 stainless steel body, the system is inclusive of the pedestal.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 227 LT/MIN. (60 GPM)
* Flow rate osmotized water: 272 LT/MIN. (72 GPM)
* Power supply: 6x 200-240V 50/60Hz 0,25A
* Rating power: 432W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 969 x Ø 168
12012018
AISI 304 stainless steel body, the system is inclusive of the pedestal.
* Max pressure: 10 bar (145 psi)
* Ultraviolet radiation: 30.000 W/cm2
* Flow rate filtered water: 303 LT/MIN. (80 GPM)
* Flow rate osmotized water: 363 LT/MIN. (96 GPM)
* Power supply: 8x 200-240V 50/60Hz 0,25A
* Rating power: 576W.
* Philips average lamp life: 9.000h. - max. 1 year
* Dimensions (mm.): L. 969 x Ø 219
12012101
* Power supply: 220-240V 50/60Hz 0,03A
* Rating power (12012006): 5,5W.
* Rating power (12012007): 8W.
For codes: 12012006 - 12012007
12012102
* Power supply: 220-240V 50/60Hz 0,07A
* Rating power (12012008): 14W.
* Rating power (12012009): 21W.
For codes: 12012008 - 12012009
12012103
* Power supply: 220-240V 50/60Hz 0,11A
* Rating power: 32W.
For code: 12012010
12012104
* Power supply: 220-240V 50/60Hz 0,14A
* Rating power: 40W.
For code: 12012011
12012105
* Power supply: 220-240V 50/60Hz 0,25A
* Rating power: 72W.
For code: 12012012
12012118
* Power supply: 110-240V 50/60Hz 1.03A - 0,47A
* Rating power: 98W.
Ballast with timer and control panel.
- Press "S" switch to switch display screen between lamp and ballast.
- Press "S" switch to display total runnings days of ballast.
- Press & hold on "S" switch to reset lamp life timer.
- Press & hold on "S" switch to silent end of lamp life alarm for 7 days (4 time max.)
For code: 12012013
