Reverse osmosis pressure switches, sensors and solenoid valves

Identify the component function before selecting a reverse osmosis spare. For solenoid valves, sensors and pressure switches, check the voltage, connection and operating range in the listing.

In the catalogue
Carbonators · Electrical spare parts · Solenoid valves

order
other filters

Red led OD 5mm. (10)
Red led OD 5mm. (10)
04704701
MAX RAT.:100 mW WORK. TEMP.:-40°C - +80°C
Led verde Ø 5mm. (10)
Led verde Ø 5mm. (10)
04704702
MAX RAT.:100 mW WORK. TEMP.:-40°C - +80°C
Metal led holder OD 5mm. with nut and threaded ferrule (50)
Metal led holder OD 5mm. with nut and threaded ferrule (50)
04704711
BUSHING:brass THREADED COLLET:nylon HOLE DISTANCE:2,54 mm NUT:chrome pl. brass PANEL CUTOUT:Ø 8 mm
Red normally open button
Red normally open button
04704729
Features: Voltage: 250V. Material: phenolic material Current: 0,5A
Solenoide valve 3 entrances - 1 OutPut 220V. / 24V.
Solenoide valve 3 entrances - 1 OutPut 220V. / 24V.
060007
3-ways solenoide valve, with body in food grade resin and membrane in platinic silicone 3/4" x 1/4". Flow rate: 6,7 Lt./Min. - 3,5bar. Nominal pressure: 10bar. Voltage: 220V. - AC Voltage: 24V. - DC
Solenoid valve at one way 220V.-AC / 24V.-DC / 24V.-AC
Solenoid valve at one way 220V.-AC / 24V.-DC / 24V.-AC
060008
1-way solenoide valve with body in food grade resin membrane in platinic silicone 3/4"x1/4" Flow rate: 2,5 Lt./Min. - 2,5bar Nominal pressure: 10bar
One way flowmeter solenoid valve 220V.~240V. - 50/60Hz 6VA - OD stem 10mm. (100)
One way flowmeter solenoid valve 220V.~240V. - 50/60Hz 6VA - OD stem 10mm. (100)
060077
Servo-assisted solenoid valve for water with integrated flow sensor. This valve is typically used on household appliances connected to the hydraulic network. A flow sensor, capable of measuring the volume of delivered water, and a flow limiter, capable of
details
Ambient temperature:
2 °C ÷ 60 °C
Temperature of fluid:
2 °C ÷ 70 °C
Operating pressure:
0.02 ÷ 1 MPa (0.2 ÷ 10 bar)
Flow rate:
According to the mounted regulator (2.5 to 8 l/min)
Minimum flow of signal presence:
0.6 l/min
Minimum flow of flow rate measure:
According to the flow regulator used
Accuracy of the flow measure:
According to the flow rate (+/-4.5% to +/-8%)
Hall sensor power supply:
3.8 – 24 Vdc
Resistance to Bursting:
> 6 MPa ( > 60 bar ) a 25°C
Life:
50.000 cycles - 200.000 total litres

Solenoid valve R series - 230V. AC thread 3/4" M. - quick fit JG 8mm. with plastic bracket
Solenoid valve R series - 230V. AC thread 3/4" M. - quick fit JG 8mm. with plastic bracket
060091
Solenoid valve R series - 230V. AC thread 3/4" M. - quick fit JG 8mm. with plastic bracket
One way solenoid valve 230V. thread 1/4" F. for cod. 20030023 - drain line (160)
One way solenoid valve 230V. thread 1/4" F. for cod. 20030023 - drain line (160)
060099
Solenoid valve connection faston for cod. 20030023 Normally Closed (NC).
One way solenoid valve 230V. quick fitting 6mm. for cod. 20030023 - drain line (96)
One way solenoid valve 230V. quick fitting 6mm. for cod. 20030023 - drain line (96)
060100
Solenoid valve new version with JG 6mm. quick fit for cod. 20030023
One way solenoid valve 220V.~240V. - 50/60Hz 6VA - OD stem 10mm. (100)
One way solenoid valve 220V.~240V. - 50/60Hz 6VA - OD stem 10mm. (100)
details
Ambient temperature:
2 °C ÷ 60 °C
Temperature of fluid:
25 °C ÷ 90 °C
Operating pressure:
0.02 ÷ 1 MPa (0.2 ÷ 10 bar)
Flow rate:
According to the mounted regulator (2.5 to 8 l/min)
Resistance to Bursting:
> 6 MPa ( > 60 bar ) a 25°C
Life:
50.000 cycles - 200.000 total litres
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket
20040031
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket and red flow reducer 0,25 lt.
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket and red flow reducer 0,25 lt.
20040032
Features: Structure: POM Compensator: NBR / LSR Work features Fluid direction: Unidirectional Working pressure: 0-10bar. (0-1Mpa)
Air fan cooled rotary pump engine for reverse osmosis 180W.
Air fan cooled rotary pump engine for reverse osmosis 180W.
060060
Air cooled 180W engine for reverse osmosis rotary pump. Capacitor included. * Specifications: 230VAC - 1,65AMP (7µF) * Frequency: 50Hz * Power: 180W * Motor Rotation: 1400 RPM
Rotary pump engine for reverse osmosis and water coolers 180W.
Rotary pump engine for reverse osmosis and water coolers 180W.
060084
Air cooled 180W engine for reverse osmosis rotary pump. Capacitor included. * Specifications: 230VAC - 1,65AMP (7µF) * Frequency: 50Hz * Power: 180W * Motor Rotation: 1400 RPM
Rotary pump engine for reverse osmosis and water coolers 120W.
Rotary pump engine for reverse osmosis and water coolers 120W.
060102
Air cooled 120W engine for reverse osmosis rotary pump. Capacitor included. * Specifications: 230-240/220 VAC - 1,0AMP * Frequency: 50/60 Hz * Power: 120W * Motor Rotation: 1320 RPM
Air fan cooled rotary pump engine with fan cover for reverse osmosis 180W.
Air fan cooled rotary pump engine with fan cover for reverse osmosis 180W.
060110
Air cooled 180W engine for reverse osmosis rotary pump. Capacitor included. * Specifications: 230VAC - 1,65AMP (7µF) * Frequency: 50Hz * Power: 180W * Motor Rotation: 1400 RPM
Reverse osmosis, water coolers rotary vane pump engine 150W.
Reverse osmosis, water coolers rotary vane pump engine 150W.
060136
Air cooled 150W engine for reverse osmosis rotary pump. Capacitor included. - Specifications: 230VAC - 1,65AMP (7µF) - Frequency: 50Hz - Power: 150W - Motor Rotation: 1370/1670 RPM
Rotary pump engine for reverse osmosis and water coolers 560W.
Rotary pump engine for reverse osmosis and water coolers 560W.
060144
Air cooled 560W engine for reverse osmosis rotary pump. Capacitor included. - Specifications: 230VAC - 4,2AMP (14µF) - Frequency: 50Hz - Power: 560W - Motor Rotation: 1360 RPM
Replacement 7 MF capacitor for code 060084
Replacement 7 MF capacitor for code 060084
060145
Air cooled 180W engine for reverse osmosis rotary pump. Capacitor included. * Specifications: 230VAC - 1,65AMP (7µF) * Frequency: 50Hz * Power: 180W * Motor Rotation: 1400 RPM
Replacement bracket for rotary pump engines 060084, 060136
Replacement bracket for rotary pump engines 060084, 060136
060159
Replacement bracket for rotary pump engines 060084, 060136
Chassis back plug for hole OD from 15 to 18 mm.
Chassis back plug for hole OD from 15 to 18 mm.
04704713
Material:ABS Dimensions: 21,5x12x2 mm. Metal sheet thickness: 0,8-3,2 mm.
Chassis back plug for hole OD from 18,4 to 22 mm.
Chassis back plug for hole OD from 18,4 to 22 mm.
04704752
Material:ABS Dimensions: 25,3x12,7x2 mm. Metal sheet thickness: 0,8-3,2 mm.
115 products found - 4 pages
|< <<
