Pentek filter housings Big Blue® & Big Clear 10", 20" - IN/OUT 3/4", 1", 1-1/2"
Pentek filter housings Big Blue® & Big Clear 10", 20" - IN/OUT 3/4", 1", 1-1/2"
09505001
• Large capacity housing suitable for high flow applications • 10" and 20" lengths available in opaque and clear • Pressure relief/bleed on inlet side of cap • Accepts 41/2" diameter cartridges Big Blue® Filter Housings offer the versatility to meet all of your large-capacity filtration needs, including high-flow and heavy-sediment applications. The extra large housing allows for greater cartridge capacity, reducing the number of vessels required for high flow-rate applications. Sumps are constructed of
details
Dimensions 10" - IN/OUT 3/4":
13-1/8" x 7-1/4" (333 mm x 184 mm)
Initial psi @ Flow Rate (gpm) 10" - 3/4":
2 psi @ 15 gpm (0.1 bar @ 57 Lpm)
Housing Big Blue:
Polypropylene
Cap:
Polypropylene (HFPP)
Button Assembly:
300-series Stainless Steel, EPDM, and Polypropylene
O-ring:
Buna-N
Temperature Rating:
100ºF (37.8ºC) max.
Maximum Pressure 10":
100 psi (6.9 bar)

Pentek Pleated polyester/cellulose sediments cartridges ECP Series 9-3/4", 20", 9-3/4"BB, 20"BB - 1, 5, 20, 50 micron
Pentek Pleated polyester/cellulose sediments cartridges ECP Series 9-3/4", 20", 9-3/4"BB, 20"BB - 1, 5, 20, 50 micron
09515001
ECP Series Pleated Cellulose Polyester Cartridges • Replaces CP and HFCP Series cartridges • Special formulation of resin-impregnated cellulose and polyester fibers • Provides higher wet strength than regular cellulose cartridges • Minimal unloading and media migration ECP Series cartridges are manufactured from a special formulation of resin-impregnated cellulose and polyester fibers. This unique blend of materials provides a higher wet strength than regular cellulose cartridges. It also provides high
details
Initial psi@Flow Rate(gpm) ECP5-10:
<1 psi @ 10 gpm (<0.1 bar @ 38 Lpm)
Initial psi@Flow Rate(gpm) ECP5-10BB:
<1 psi @ 20 gpm (<0.1 bar @ 76 Lpm)
Filter Media:
Cellulose Polyester
Core:
Polypropylene
End Caps:
Vinyl Plastisol
Temperature Rating:
40 - 125ºF (4.4 - 51.7ºC)
Endcap Color ECP5-10:
White

Pentek Pleated polyester/cellulose sediments cartridges R Series 4-7/8", 9-3/4", 20", 9-3/4"BB, 20"BB - 30, 50  micron
Pentek Pleated polyester/cellulose sediments cartridges R Series 4-7/8", 9-3/4", 20", 9-3/4"BB, 20"BB - 30, 50  micron
09516001
R SERIES PLEATED POLYESTER CARTRIDGES • Pleated design maximizes dirt-holding capacity • Versatile and reusable, allowing for a variety of uses • Durable polyester media is bacteria and chemical resistant • Nominal 30-micron rating (R30) and nominal 50-micron rating (R50) R Series cartridges are manufactured from a durable, non-woven and reusable polyester fabric that is suitable for a wide range of filtration uses. The media is pleated around a polypropylene core for added strength and the ends are im
details
Initial psi @ Flow Rate (gpm) R30-478:
<1 psi @ 10 gpm (<0.1 bar @ 38 Lpm)
Initial psi @ Flow Rate (gpm) R30:
<1 psi @ 10 gpm (<0.1 bar @ 38 Lpm)
Initial psi @ Flow Rate (gpm) R50:
<1 psi @ 10 gpm (<0.1 bar @ 38 Lpm)
Initial psi @ Flow Rate (gpm) R30-BB:
<1 psi @ 10 gpm (<0.1 bar @ 38 Lpm)
Initial psi @ Flow Rate (gpm) R50-BB:
<1 psi @ 10 gpm (<0.1 bar @ 38 Lpm)
Initial psi @ Flow Rate (gpm) R30-20BB:
<1 psi @ 20 gpm (<0.1 bar @ 76 L/min)
Filter Media:
Non-Woven Polyester
End Caps:
Vinyl Plastisol
Core:
Polypropylene
Temperature Rating:
40 - 125ºF (4.4 - 51.7ºC)

Pentek sediments cartridges Polydepth series 9-7/8", 20", 30", 40" - 1, 5, 10, 25, 50 micron
Pentek sediments cartridges Polydepth series 9-7/8", 20", 30", 40" - 1, 5, 10, 25, 50 micron
09519001
POLYDEPTH® SERIES POLYPROPYLENE CARTRIDGE • Thermally bonded polypropylene micro-fiber construction for higher filtration efficiency • Consistent flow rate and superior filtration performance • Available in a wide range of micron ratings and lengths • Will not impart taste, odor or color to water being filtered • Ideal for a wide variety of industrial filtration The POLYDEPTH® filtration cartridge is constructed of thermally bonded polypropylene microfibers to ensure high efficiency. The filter incorp
details
Initial psi @ Flow Rate (gpm) PD-10-20:
<2 psi @ 5 gpm (<0.14 bar @ 19 Lpm)
Initial psi @ Flow Rate (gpm) PD-5-30:
<2 psi @ 7 gpm (<0.14 bar @ 26.5 Lpm)
Filter Media:
Polypropylene
Temperature Rating:
40 - 175ºF (4.4 - 79.4ºC)

Pentek sediments cartridges Dual-Gradient Density DGD Series 9-3/4"BB, 20"BB - 75 to 1  micron
Pentek sediments cartridges Dual-Gradient Density DGD Series 9-3/4"BB, 20"BB - 75 to 1  micron
09520001
DGD Series Dual-Gradient density cartridges • Manufactured from pure 100% polypropylene • Designed for purity and chemical compatibility • Spun fibers form a true gradient density from outer to inner surfaces DGD Series cartridges are manufactured from 100% pure polypropylene and are sized for use in our Big Blue® filter housings. DGD Series cartridges are designed for purity and will not impart taste, odor or color to the liquid being filtered. Additionally, the polypropylene construction provides supe
details
Initial psi @ Flow Rate DGD-5005:
<1 psi @ 10 gpm (<0.1 bar @ 38 Lpm)
Initial psi @ Flow Rate DGD-7525:
<1 psi @ 10 gpm (<0.1 bar @ 38 Lpm)
Initial psi @ Flow Rate DGD-5005-20:
<1 psi @ 20 gpm (<0.1 bar @ 76 Lpm)
Filter Media:
Polypropylene
Temperature Rating:
40 - 145ºF (4.4 - 62.8ºC)

Pentek Polypropylene Wound sediments cartridges CW/BSWP Series 10"BB, 20"BB - from 50 to 5 micron
Pentek Polypropylene Wound sediments cartridges CW/BSWP Series 10"BB, 20"BB - from 50 to 5 micron
09521002
• String-wound design reduces fine sediment from a variety of fluids • Withstands temperatures up to 165° F (73.9° C) • Economically priced CW and WP Series cartridges are manufactured from a durable polypropylene cord that is wound around a rigid polypropylene core. They are an economical solution to reduce fine sediment, including sand, silt, rust and scale particles. CW cartridges are very economical and wound in a standar
details
Filter Media:
Polypropylene
Core:
Polypropylene
Temperature Rating:
40 - 165ºF (4.4 - 73.9ºC)

Pentek Carbon block Cartridges CBC Series 5", 9-3/4", 20", 9-3/4"BB, 20"BB - 0,5 micron
Pentek Carbon block Cartridges CBC Series 5", 9-3/4", 20", 9-3/4"BB, 20"BB - 0,5 micron
09532002
CBC SERIES CARBON BLOCK CARTRIDGES • Nominal 0,5 micron rating* • 99,5% reduction of Cryptosporidium, Giardia* • Premium high capacity bad taste & odor and chlorine taste & odor reduction* • Enhanced dirt holding capacity* CBC Series cartridges are highly effective at reducing unwanted taste, odor and chlorine: taste & odor, from potable drinking water. The unique structure of the carbon block enables it to reduce Giardia, Cryptosporidium, Entamoeba, and Toxoplasma cysts and fine sediment particles d
details
Initial bar @ Flow Rate CBC-5:
0.48 bar @ 3.8 Lpm
Capacity CBC-5:
11.400 L @ 3.8 Lpm
Initial bar @ Flow Rate CBC-10:
0.23 bar @ 7.6 Lpm
Capacity CBC-10:
75.700 L @ 7.6 Lpm
Initial bar @ Flow Rate CBC-20:
0.21 bar @ 7.6 Lpm
Capacity CBC-20:
170.300 L @ 7.6 Lpm
Initial bar @ Flow Rate CBC-10BB:
0.32 bar @ 7.6 Lpm
Capacity CBC-10BB:
189.300 L @ 7.6 Lpm
Initial bar @ Flow Rate CBC-20BB:
0.38 bar @ 15.1 Lpm
Capacity CBC-20BB:
567.800 L @ 15.1 Lpm
Filter Media:
Bonded PAC
End Caps:
Polypropylene
Outer Wrap:
Polyolefin
Netting:
Polyethylene
Gasket:
Buna-N
Temperature Rating:
40 - 180ºF (4.4 - 82.2ºC)

Pentek Carbon block Cartridges EPM Series 9-3/4", 20", 9-3/4"BB, 20"BB - 10 micron
Pentek Carbon block Cartridges EPM Series 9-3/4", 20", 9-3/4"BB, 20"BB - 10 micron
09532001
EPM series modified epsilon carbon-briquette cartridge. • Nominal 10-micron rating* • Enhanced dirt holding capacity for extended cartridge life* • Bad taste & odor and chlorine taste & odor reduction* • Lowest pressure drop • Economically priced EPM Series cartridges are a modified version of our EP Series cartridge. An economical price makes this cartridge suitable for taste, odor and chlorine taste & odor reduction, as well as sediment filtration.* EPM Series cartridges are manufactured using a pat
details
Initial psi @ Flow Rate (gpm) EPM10:
1.5 psi @ 1 gpm (0.10 bar @ 3.8 Lpm)
Capacity EPM-10:
3,000 gallons @ 1 gpm (11,400L @ 3.8 Lpm)
Initial psi @ Flow Rate (gpm) EPM-20BB:
4 psi @ 4 gpm (0.28 bar @ 15 Lpm)
Capacity EPM-20BB:
30,000 gallons @ 4 gpm (113,500L @ 15 Lpm)
Filter Media:
Bonded PAC
End Caps:
Polypropylene
Outer Wrap:
Polyolefin
Netting:
Polyethylene
Gasket:
Buna-N
Temperature Rating:
40 - 180ºF (4.4 - 82.2ºC)

Pentek dual purpose powdered-activated carbon cartridges C Series 5", 9-3/4", 20"  - 1, 5 micron
Pentek dual purpose powdered-activated carbon cartridges C Series 5", 9-3/4", 20"  - 1, 5 micron
09523001
C SERIES DUAL PURPOSE POWDERED-ACTIVATED CARBON CARTRIDGES • Economically priced • Provides sediment filtration, bad taste & odor and chlorine taste & odor reduction* • High dirt-holding capacity • Available in three sizes and two micron ratings • Recommended for chlorinated water supplies C Series cartridges offer an economical solution for all of your general-purpose water filtration needs. Constructed of a carbon impregnated cellulose media, these dual-purpose cartridges filter out fine sediment pa
details
Initial psi @ Flow Rate (gpm) C2:
2.0 psi @ 2 gpm (0.1 bar @ 7.6 Lpm)
Capacity C2:
>1250 gallons @ 0.5 gpm (>4700L @ 1.9 Lpm)
Filter Media:
PAC Impregnated Cellulose
End Caps:
Vinyl Plastisol (C1-C2) / Polypropylene (C8)
Netting:
Polyethylene
Core:
Polypropylene
Reinforcement Backing:
Poliestere (C8) Cellulosa Poliestere (C1-C2)
Gasket:
Buna-N
Temperature Rating (C1, C2, C1-20):
40 - 125ºF (4.4 - 51.7ºC)
Temperature Rating (C8):
40 - 145ºF (4.4 - 62.8ºC)

Pentek granular Carbon Cartridges GAC Series 9-3/4", 20"
Pentek granular Carbon Cartridges GAC Series 9-3/4", 20"
09526001
GAC SerieS granular activated carbon cartridges • effective bad taste & odor and chlorine taste & odor reduction* • designed for maximum adsorption • Post-Filter to reduce carbon fines • Available in a variety of sizes and flow rates GAC Series cartridges effectively reduce unwanted tastes, odor and chlorine taste & odor from your drinking water.* They are designed to allow maximum contact between the water and carbon, ensuring maximum adsorption. The construction of the cartridge allows water to enter
details
Initial psi @ Flow Rate (gpm) GAC20:
16 psi @ 2.0 gpm (1.1 bar @ 7.6 Lpm)
Capacity GAC-20:
10,000 gallons @ 2.0 gpm (37,800L @ 7.6 Lpm)
Filter Media:
Granular Activated Carbon GAC
End Caps:
Polystyrene
Post-Filter:
Spun Polypropylene
Outer Casing:
Polystyrene
Expansion Pad:
Polypropylene
Gasket:
Buna-N (top) - Santoprene™ (bottom)
Temperature Rating:
40 - 125ºF (4.4 - 51.7ºC)

Pentek GS-10RO coconut shell Granular Activated Carbon (GAC) inline filter 1/4" FPT, 1/4" J.G. 2"x10" - 5 micron (25)
Pentek GS-10RO coconut shell Granular Activated Carbon (GAC) inline filter 1/4" FPT, 1/4" J.G. 2"x10" - 5 micron (25)
09557001
The Series inline filters offer an extensive variety of products to meet your most challenging applications. PENTEK in-line filters are designed for use on any point of use drinking water appliance including reverse osmosis (RO) systems, distillation systems, food service equipment, bottleless water coolers, water fountains, refrigerators and other water dispensing devices. The series in-line filtration features coconut shell granular activated carbon.
details
Service life GS-10RO:
3,308 gallons (12,522L) max. 1 year
Flow rate:
0,5 gpm (1,9L/min)
Temperature Rating:
40 - 100°F (4,4 - 37,8°C)
Working pressure:
20-125 psi (1,4-8,62 bar)

Pentek Pleated Carbon Impregnated Polyester cartridges NCP series 9-3/4", 20", 9-3/4"BB, 20"BB - 10 micron
Pentek Pleated Carbon Impregnated Polyester cartridges NCP series 9-3/4", 20", 9-3/4"BB, 20"BB - 10 micron
09524001
NCP SERIES NON-CELLULOSE CARBON IMPREGNATED PLEATED CARTRIDGES • Non-cellulose media resists bacterial attack. • Provides sediment filtration and chlorine taste & odor reduction. • Pleated for maximum dirt-loading capacity. • Nominal 10-micron rating. NCP Series cartridges are constructed from a carbonimpregnated non-cellulose media. They offer sediment-filtration, as well as taste, odor and chlorine taste and odor reduction in one cartridge. Unlike cellulose cartridges, NCP Series cartridges are resis
details
Initial psi @ Flow Rate (gpm) NCP-BB:
2 psi @ 8 gpm (0.1 bar @ 30 Lpm)
Capacity NCP-BB:
500 gallons @ 2 gpm (1890L @ 7.6 Lpm)
Initial psi @ Flow Rate (gpm) NCP-20:
2 psi @ 5 gpm (0.1 bar @ 19 Lpm)
Capacity NCP-20:
450 gallons @ 2 gpm (1700L @ 7.6 Lpm)
Filter Media:
Pleated Carbon-Impregnated Polyester
End Caps:
Vinyl Plastisol
Netting:
Polypropylene
Core:
Polypropylene
Temperature Rating:
40 - 125ºF (4.4 - 51.7ºC)

Pentek GS-10CAL/RO remineralizer PH adjustment in line filter coconut (GAC) 1/4" FPT 2"x10" - 20 micron (12)
Pentek GS-10CAL/RO remineralizer PH adjustment in line filter coconut (GAC) 1/4" FPT 2"x10" - 20 micron (12)
09559001
This Pentek GS-10CAL/RO-B Inline Filter Cartridge Replacement is a 10" combination in-line filter composed of coconut shell granular activated carbon (GAC) and calcite. It can be utilized in various applications to correct low pH levels, polish water, brew better tasting coffee, tea, or other beverages (or in numerous other food service applications), as a post filter in many reverse osmosis systems, and more. It reduces the bad taste and odor of chlorine as well as sediment and increases the pH level of wa
details
Service life:
2,000 gallons (7,570L) max. 1 anno
Flow rate:
1,0 gpm (3,8L/min)
Temperature Rating:
40 - 100°F (4,4 - 37,8°C)
Working pressure:
20-125 psi (1,4-8,62 bar)
Pentek mixed bed deionization cartridges series PCF 9-3/4", 20", 20"BB
Pentek mixed bed deionization cartridges series PCF 9-3/4", 20", 20"BB
09547001
PCF SERIES MIXED BED DEIONIZATION CARTRIDGES • Designed for deionizing water up to 16 megohms. • All materials and construction are FDA-compliant. • Three sizes and capacities. PCF Series filter cartridges have been developed in response to the requirements for deionized water in many industries. They are manufactured using an FDA-compliant resin that has been subjected to additional post-production steps to minimize the total organic carbon (TOC) level. These high-capacity, semi-conductor-grade res
details
Initial psi @ Flow Rate PCF1-10MB:
1.5 psi @ 0.25 gpm(0.10 bar @ 0.95 Lpm)
Capacity Grains PCF1-10MB:
270 (17.500)
Suggested Flow Rate PCF1-10MB:
0.25 gpm (0.95 Lpm)
Initial psi @ Flow Rate PCF1-20MB:
3.4 psi @ 0.50 gpm (0.23 bar @ Lpm)
Capacity Grains PCF1-20MB:
(mg TDS as CaCO3) 600 (38,800)
Suggested Flow Rate PCF1-20MB:
0.50 gpm (1.9 Lpm)
Initial psi @ Flow Rate BBF1-20MB:
1.10 psi @ 1.25 gpm (0.076 bar @ 4.7 Lpm)
Capacity Grains BBF1-20MB:
(mg TDS as CaCO3) 1850 (120,000)
Suggested Flow Rate BBF1-20MB:
1.25 gpm (4.7 Lpm)
Filter Media:
Mixed Bed DI Resins
End Caps:
Polypropylene
Shell:
Polypropylene
Pre-filter:
Polypropylene
Post-filter:
Polypropylene
Gasket:
Buna-N
Temperature Rating:
40 - 100°F (4,4 - 37,8°C)

Pentek QC10 series Quick Change water filters
Pentek QC10 series Quick Change water filters
09560001
The PENTEK Quick Change series for drinking water is suitable for applications at the point of use, such as installing undersink. All these systems have the NSF certification, are equipped with many features for the reduction of contaminants and the Quick Change system that allows the quick replacement of the cartridge in the presence of water under pressure. This feature eliminates the need for additional shut-off valves on the head. The filtration system offers excellent functionality of chemicals reduct
details
Capacity CBRR:
500 gallons (1,890L) 6 months
Capacity GACR:
2.500 gallons (9,460L) 9 months
Working pressure:
30-125 psi (2,1-8,62 bar)
Temperature Rating:
40 - 100°F (4,4 - 37,8°C)
Flow rate CBRR:
0,5 gpm (1,9L/min)
Flow rate GACR:
0,75 gpm (2,8L/min)
Micron rating CBRR:
0,5
Micron rating GACR:
--
Turbidity:
NTU max = 5
