DMfit quick fit fittings black series acetal resin metric size food&drink beverage compressed air flow systems

order
other filters

SS water carbonator 1,2lt. 5/16" OD stem with fittings 1/4"F.
SS water carbonator 1,2lt. 5/16" OD stem with fittings 1/4"F.
060074
This product is planned for the production of sparkling water using exclusively carbon dioxide up to the maximum pressure of 7 bar with potable water. Technical features: - Level control with one probe - Ground Faston - Two single check valves on inlet water - Two single check valves on inlet co2 Gas - Water inlet thread 1/4” gas - Gas inlet thread 1/4” gas - Output probe fitting connection 8mm(5/16”) - Bottom drain with cap - Max. operating pressure = 7bar(101psi) - Bursting pressure = 80bar(1
316 SS water carbonator from 0,650lt. to 2,700lt. with safety valve
316 SS water carbonator from 0,650lt. to 2,700lt. with safety valve
060116
- Level control with one probe; - Made of stainless steel AISI 316; - Antibacterial silver welds; - Horizontal or vertical functioning; - Both internal and external pickling (metal)*. Technical features: - Water inlet stem OD8mm. - Water outlet stem OD8mm. - Co2 inlet stem OD8mm. - Max. operating pressure= 7bar. (102 psi). - Safety valve breather start= 8bar. (116psi). - Bursting pressure = > 20 bar. (290 psi). - Carbonator max. capacity = 2lt./min. 12bar.(732psi) h2o, pump 300lt./h.
details
Misures Ø x H - 0,650lt. (mm):
89x115
Misures Ø x H - 0,750lt. (mm):
89x145
Misures Ø x H - 0,850lt. (mm):
89x165
Misures Ø x H - 1,100lt. (mm):
89x195
Misures Ø x H - 1,200lt. (mm):
89x210
Misures Ø x H - 1,300lt. (mm):
89x228
Misures Ø x H - 1,750lt. (mm):
89x298

316 SS water carbonator from 0,250lt. to 1,27lt. IN/OUT 1/8" F.
316 SS water carbonator from 0,250lt. to 1,27lt. IN/OUT 1/8" F.
060079
Technical features: - Level control with double probe - Made of stainless steel AISI 316 - Antibacterial silver welds - Horizontal or vertical functioning - Both internal and external pickling (metal) - Water inlet thread 1/8” gas - Water outlet thread 1/8” gas - Gas inlet thread 1/8” gas - Max. operating pressure = 8,5 bar (123 psi) - Bursting pressure = > 20 bar (290 psi) - Carbonator max. capacity = 2lt./min 12bar(732psi) h2o, pump 300lt./h., 4bar(58psi) Co2. Pickling is a metal surface tr
details
Misures Ø x H - 0,250lt. (mm):
90x100
Misures Ø x H - 0,510lt. (mm):
90x140
Misures Ø x H - 0,760lt. (mm):
90x180
Misures Ø x H - 1,020lt. (mm):
90x220
Misures Ø x H - 1,270lt. (mm):
90x260

304 SS double stage water carbonator 2,000ltr. with safety valve - vertical
304 SS double stage water carbonator 2,000ltr. with safety valve - vertical
060119
Technical features: - Made of stainless steel AISI 304, - Probe for level control, - Probe for temperature control, - Overall capacity: 2ltr., - Capacity per partition: 1ltr. lower partition H2O still - 1 ltr. upper partition SODA, - Cast TIG welding, - Vertical functioning, - Both internal and external pickling and passitivation (metal) - Water inlet thread: OD 8mm., - Water outlet thread: OD 8mm., - Gas inlet thread: OD 8mm., - Max. operating pressure: 7bar (101 psi), - Bursting pre
Female red isolated faston dim. 6,35mm. (100)
Female red isolated faston dim. 6,35mm. (100)
04704715
Features: Material: tinned brass Color: red Max. rating: 10A
Female yellow isolated faston dim. 6,35mm. (100)
Female yellow isolated faston dim. 6,35mm. (100)
04704716
Features: Material: tinned brass Color: yellow Max. rating: 24A
Female faston dim. 6,35mm.
Female faston dim. 6,35mm.
04704718
Features: Material: tinned brass Max. working temperature: 110°C Cable diameter: 0,30-0,80 mm.
Female faston cover dim. 6,3mm.
Female faston cover dim. 6,3mm.
04704719
Insertion from behind. Features: Material: natural polyethylene Insulator diameter: 2,5mm.
Ring cable lug OD 4,3mm. (100)
Ring cable lug OD 4,3mm. (100)
04704717
Features: Material: tinned brass Color: red Max. rating: 19A
Shrinkable sheath OD 3,2/1,6 mm.
Shrinkable sheath OD 3,2/1,6 mm.
04704722
Flame retardant and resistant to solvents and chemical agents. Flexible and highly insulated. Many useful applications including terminal connections, electrical insulation, mechanical protection, wire identification and color coding. Features: Shrink fact: 2:1 Material: polyolefin Shrink temperature: 120°C Work temperature: -40° - 135°C Restrict diameter: 1,6mm. Normal diameter: 3,2mm.
Male faston with 6,35mm. straight pitch
Male faston with 6,35mm. straight pitch
04704741
Features: Material: natural brass
Male faston cover 6,35mm. pitch
Male faston cover 6,35mm. pitch
04704742
Features: Material: pvc Color: natural
Solenoid valve at one way 220V.-AC / 24V.-DC / 24V.-AC
Solenoid valve at one way 220V.-AC / 24V.-DC / 24V.-AC
060008
1-way solenoide valve with body in food grade resin membrane in platinic silicone 3/4"x1/4" Flow rate: 2,5 Lt./Min. - 2,5bar Nominal pressure: 10bar
Solenoid valve R series - 230V. AC thread 3/4" M. - quick fit JG 8mm. with plastic bracket
Solenoid valve R series - 230V. AC thread 3/4" M. - quick fit JG 8mm. with plastic bracket
060091
Solenoid valve R series - 230V. AC thread 3/4" M. - quick fit JG 8mm. with plastic bracket
One way flowmeter solenoid valve 220V.~240V. - 50/60Hz 6VA - OD stem 10mm. (100)
One way flowmeter solenoid valve 220V.~240V. - 50/60Hz 6VA - OD stem 10mm. (100)
060077
Servo-assisted solenoid valve for water with integrated flow sensor. This valve is typically used on household appliances connected to the hydraulic network. A flow sensor, capable of measuring the volume of delivered water, and a flow limiter, capable of
details
Ambient temperature:
2 °C ÷ 60 °C
Temperature of fluid:
2 °C ÷ 70 °C
Operating pressure:
0.02 ÷ 1 MPa (0.2 ÷ 10 bar)
Flow rate:
According to the mounted regulator (2.5 to 8 l/min)
Minimum flow of signal presence:
0.6 l/min
Minimum flow of flow rate measure:
According to the flow regulator used
Accuracy of the flow measure:
According to the flow rate (+/-4.5% to +/-8%)
Hall sensor power supply:
3.8 – 24 Vdc
Resistance to Bursting:
> 6 MPa ( > 60 bar ) a 25°C
Life:
50.000 cycles - 200.000 total litres

One way solenoid valve 220V.~240V. - 50/60Hz 6VA - OD stem 10mm. (100)
One way solenoid valve 220V.~240V. - 50/60Hz 6VA - OD stem 10mm. (100)
details
Ambient temperature:
2 °C ÷ 60 °C
Temperature of fluid:
25 °C ÷ 90 °C
Operating pressure:
0.02 ÷ 1 MPa (0.2 ÷ 10 bar)
Flow rate:
According to the mounted regulator (2.5 to 8 l/min)
Resistance to Bursting:
> 6 MPa ( > 60 bar ) a 25°C
Life:
50.000 cycles - 200.000 total litres
Solenoid valve at one way 220V. quick fitting 1/4"
Solenoid valve at one way 220V. quick fitting 1/4"
060009
1-way solenoide valve with body in food grade resin membrane in platinic silicone 3/4" X 1/4" quick fitting. Flow rate: 2,5 Lt./Min. - 2,5bar. Nominal pressure: 10bar. Voltage: 220V. - AC
Solenoid valve at 2 ways 220V.-AC
Solenoid valve at 2 ways 220V.-AC
060010
2-ways solenoide valve with body in food grade resin membrane in platinic silicone 3/4"x1/4" Voltage: 220V.-AC
Solenoide valve 3 entrances - 1 OutPut 220V. / 24V.
Solenoide valve 3 entrances - 1 OutPut 220V. / 24V.
060007
3-ways solenoide valve, with body in food grade resin and membrane in platinic silicone 3/4" x 1/4". Flow rate: 6,7 Lt./Min. - 3,5bar. Nominal pressure: 10bar. Voltage: 220V. - AC Voltage: 24V. - DC
One way solenoid valve 230V. quick fitting 6mm. for cod. 20030023 - drain line (96)
One way solenoid valve 230V. quick fitting 6mm. for cod. 20030023 - drain line (96)
060100
Solenoid valve new version with JG 6mm. quick fit for cod. 20030023
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket
20040031
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket and red flow reducer 0,25 lt.
Solenoid valve R-Double series, 180°, IN thread 3/4" M, OUT 2xJG 8mm., 220V., with plastic bracket and red flow reducer 0,25 lt.
20040032
Features: Structure: POM Compensator: NBR / LSR Work features Fluid direction: Unidirectional Working pressure: 0-10bar. (0-1Mpa)
112 products found - 4 pages
|< <<
